Metal Raschig Ring
Product Introduction:
Metal Raschig Ring, has the same height and diameter. The shape is simple. It is the oldest type of chemical packing as a mass transfer media, is widely used as catalyst support.
Xintao Metal Raschig Ring, has features such as thin wall, heat resistant, high free volume, high capacity, low resistance, high separation efficiency and so on.
Material:
Carbon Steel. SS304, 304L, 410, 316, 316L, etc.
Technical Parameter:
Size (mm) | Surface area (m2/m3) | Free volume (%) | Number per m3 | Bulk density (kg/m3) |
16*16*0.3 | 330 | 95.1 | 201000 | 345 |
25*25*0.5 | 216 | 94.6 | 51000 | 357 |
38*38*0.8 | 136 | 94.6 | 15000 | 387 |
50*50*0.8 | 102 | 95.9 | 6500 | 292 |
76*76*1.0 | 71 | 96.6 | 1830 | 237 |
Typical Application:
Be especially suitable for rectification towers under vacuum to treat thermosensitive, decomposable,
polymerizable or cokable systems. Be widely used in packing towers in petrochemical industry, chemical
fertilizer industry and environmental protection, etc.
Normal Package:
1m3/Super sack.
