Plastic Raschig Ring
Product Introduction:
Packing Mall plastic raschig ring is the first generation of random tower packing.
The plastic Rashig ring has a unique hollow cylindrical shape. Because of its simple structure, light weight, easy to manufacture and operate. The plastic raschig ring is characterized by high volume, light weight and excellent corrosion resistance.
It is suitable for a variety of vaporization, degassing, absorption and distillation processes, widely used in the petroleum industry, chemical industry, alkali metal chloride industry and natural gas industry.
The pressure of Plastic raschig ring is reduced and the energy consumption is low.
Plastic raschig ring is widely used in drying towers, absorption towers, cooling towers, washing towers and regeneration towers. Plastic raschig rings come in different materials, wall thickness and diameter. Specifications can be customized to your requirements.
Technical Parameter:
Model | Raschig ring | ||||
Material | PP,RPP,PE,PVC,CPVC,PVDF,etc. | ||||
D*H*T | Number per m³ | Bulk density | Surface area | Free volume | Specification of PP raschig ring |
(mm) | PCS | (kg/m³) | (m²/m³) | (%) | |
15*15*0.3 | 240000 | 385 | 360 | 94 | |
25*25*0.3 | 51000 | 231 | 215 | 96 | |
38*38*0.4 | 14500 | 207 | 135 | 96 | |
50*50*0.5 | 6300 | 200 | 105 | 96 | |
80*80*0.8 | 1600 | 200 | 80 | 96 | |
Typical Application | Absorption, scrubbing, and stripping services | ||||
Package : | Jumbo bag; | ||||
